First Ever eAWD Corvette E-Ray Comes True

Today is January 17th, 2023 and finally the question of will they or won't they has been answered!

2024 eAWD Corvette E-Ray

Chevrolet has released the details of the upcoming 2024 Corvette E-Ray. The buzz on the interwebs has been stirring for months about a potential electric Corvette and even with all the spy shots, Chevrolet never officially said that one would be coming any time soon.



Well, as of this morning, Chevrolet has made it offical and there will be a 2024 Corvette E-Ray going into production.

For a feeling of immediate thrust, Chevrolet has paired their 495 horsepower 6.2L LT2 with a 160 horsepower electric motor. Now the LT2 will remain in the same location powering the rear wheels just like the Stingray is currently done. The electric motor is going to power the front wheels via is 1.9 kWh batter pack that is located between the seats. So that would make a total of 655 horsepower from both the electric motor and the LT2.



This whole combination would end up creating the quickest production Corvette in history, clocking a 2.5 seconds 0-60 mph time and flying through the quarter mile in 10.5 seconds. Even though these times are based on initial movement there is no doubt that this is going to be one quick Corvette.

2024 eAWD Corvette E-Ray

2024 E-Ray Propulsion System

The system that Chevrolet has put in place is going to be one that is going to be in a constant state of education. The E-Rays' intelligent eAWD system is slated to have programming that will give feed back of the road conditions while seamlessly adapting to any road conditions and driver need.



That system allows for a "no need" plug-in charging for the E-Ray's battery. They have adapted regenerative energy from coasting and braking to fuel the charging system along with plenty of new features listed below.

2024 eAWD Corvette E-Ray

Additional features and technologies of the all-new E-Ray include:

- Stealth Mode, an electric drive mode for the street, up to 45 mph

- New lightweight lithium-ion 12-volt battery that supports the LT2 V-8 engine’s stop/start functionality

- Standard Brembo Carbon Ceramic brake system for optimal braking performance

- Standard Magnetic Ride Control 4.0 with three distinct suspension settings

- Staggered 20- and 21-inch wheels with Michelin Pilot Sport all-season tires. Michelin Pilot Sport 4S summer tires are available with an optional performance package

- Low, wide stance with crafted body styling that is 3.6 inches wider overall than Stingray

- Visceral sound experience that embodies the car’s dominating presence. The electric front motor works in harmony with the LT2 engine to create an invigorating sound

- Enhanced roster of driver assistance technologies (shared with all 2024 Corvette models), including Lane Keep Assist with Lane Departure Warning, Forward Collision Alert and Automatic Emergency Braking.

2024 eAWD Corvette E-Ray

Production and Pricing Availability:

The E-Ray will start to be sold towards the end of the 2023 year in North America.  Production will take place at the iconic Bowling Green Assembly plant located in Kentucky using US and globally source parts.  Select global markets may see both a LHD and RHD configurations that will become available in their area.

Pricing for the E-Ray is going to start with an MSRP of $104,295 for the 1LZ Coupe and $111,295 for the 1LZ Convertible model.

2024 eAWD Corvette E-Ray

Specifications:

PERFORMANCE

0-60 mph: 2.5 seconds (approx.)

Quarter-mile: 10.5 @ 130 mph (209 km/h) (approx.)

Max Lateral G Force: 1.1g

*Based on initial vehicle movement.

*On a 300-foot skid pad. When equipped with available summer-only performance tire.

ENGINE

Type: LT2 6.2L V-8 VVT with direct injection and Active Fuel Management (cylinder deactivation) and Stop/Start

Bore & Stroke (in. / mm): 4.06 x 3.62 / 103.25 x 92

Block Material: A319-T7 cast aluminum with cast-in iron cylinder liners and nodular main bearing caps

Oiling System: Dry sump-type (7.5-qt. capacity); includes oil-spray piston cooling

Oil Type: Dexos 2 0W40 synthetic

Cylinder Head Material: 319-T7 cast aluminum

Combustion Chamber Volume: 59cc

Compression Ratio: 11.5:1

Valvetrain: Overhead valve, two valves per cylinder; dual-equal variable valve timing

Valve Size (in. / mm): 2.13 / 54 hollow (intake) & 1.59 / 40.4 sodium filled (exhaust)

Fuel Delivery: Direct injection with Active Fuel Management: Max pressure: 2,900 psi (20 Mpa / 200 bar)

Firing Order: 1-8-7-2-6-5-4-3 (all cylinders); 1-7-6-4 (with deactivation)

Throttle Body: 87mm single bore (electronic)

ECU: GM E99 (32-bit processing)

Horsepower (hp / kW): 495 / 369 @ 6450 rpm

Torque (lb.-ft. / Nm): 470 / 637 @ 5150 rpm

ELECTRIFICATION SYSTEM:

Type: Single motor and gearset

Motor: Permanent magnetic drive motor

Power: 160 hp / 120 kW

Torque (lb.-ft. / Nm): 125 / 165 @ motor

Battery Type:m Lithium-ion

Energy: 1.9 kWh

Combined Power (with engine): 655 hp / 481 kW

CHASSIS & SUSPENSION

Front Suspension: FE5 Short/long arm (SLA) double wishbone, forged aluminum upper and cast aluminum L-shape lower control arms; monotube shock absorbers; Magnetic Selective Ride Control 4.0. Adjustable front lift with memory is available

Rear Suspension: FE5 Short/long arm (SLA) double wishbone, forged aluminum upper and cast aluminum L-shape lower control arms; direct-acting stabilizer bar; monotube shock absorbers; Magnetic Selective Ride Control 4.0

Steering Type: Variable-ratio rack-and-pinion with electric power assist; includes Active Steer Stops with Magnetic Ride Control 4.0

Steering ratio: 15.7:1

Turning Circle (ft. / m): 36.4 / 11.1

Brake Type: Front and rear eBoost-assisted carbon ceramic discs with Brembo six-piston/monobloc front calipers and four-piston/monobloc rear calipers

Brake Rotor Size (in. / mm): Front: 15.7 x 1.5 / 398 x 38

Rear: 15.4 x 1.3 / 391 x 34

Wheel Size:

Front: 20-inch x 10-inch (w/5 x 120mm bolt pattern)

Rear: 21-inch x 13-inch (w/5 x 120mm bolt pattern)

Tire Size:

Front: 275/30ZR20

Rear: 345/25ZR21

EXTERIOR DIMENSIONS

Wheelbase (in. / mm): 107.2 / 2722

Overall Length (in. / mm): 184.6 / 4699

Overall Width (in. / mm): 79.7 / 2025

Overall Height (in. / mm): 48.6 / 1235

Track (in. / mm): Front: 66.3 / 1685

Rear: 66.1 / 1678

INTERIOR DIMENSIONS

Headroom (in. / mm): 37.9 / 962

Legroom (in. / mm): 42.8 / 1087

Shoulder Room (in. / mm): 54.4 / 1382

Hip Room (in. / mm): 52 / 1321

WEIGHTS & CAPACITIES

Dry Weight (lb. / kg):

3774 / 1712 (coupe)

3856 / 1749 (convertible)

Cargo Volume (cu. ft. / L)1: 12.5 / 355

1Cargo and load capacity limited by weight and distribution.

FUEL TANK CAPACITY (approx.)

18.5 gal. / 70 liters

Details, Specifications, Images and Video courtesy of Chevrolet.
